Learning to make a plastic false ceiling in the bathroom

Learning to make a plastic false ceiling in the bathroom

Calculate the material

Elements of constructionTo begin with, let us consider the components from which the lathing suspended ceiling is assembled (see photo):

  • End profile.
  • Tire carrier
  • Panel (attention! Profile is chosen not plastic, but aluminum).
  • Intermediate profile.
  • Suspension

Then decide in which direction the panels will be installed (in our case, along wall B). Note, however, that the longitudinal orientation visually lengthens the bathroom, and the transverse orientation reduces it. Now measure the length of the walls in the bathroom. It's time to make a calculation.

End profile will need as much as the perimeter of the room. That is, add the lengths of all the walls and find out how many meters you need to buy (A + B + A + B = 11 m).

Components of the ceiling rack

Components of the ceiling rack

The carrier tire is mounted perpendicular to the direction of the decorative panels.
If the bathroom side B is less than one meter, then the presence of load-bearing tires is not at all necessary.Otherwise, their required amount is determined by the criterion "through every meter." For example, B = 2.5 meters, then there should be two tires. The length of each of them corresponds to the side A (3 m).

Lightweight aluminum panels have different widths, and material consumption directly depends on this. The width varies from 9 to 20 cm, the most common is 10 cm. Knowing the width of the panel (say 10 cm), we determine how many strips the rack ceiling will consist of: 300 cm / 10 cm = 30 panels. The length of each is 2.5 meters.

Intermediate profile on the slatted ceiling in the bathroom will go as much as the bearing bus.

Suspension secures carrier tire every meter. In our case there should be 4 of them (2 for each tire).

Now you have everything you need to start collecting the ceiling with your own hands.

Get to work slowly, carefully making measurements. This will guarantee a perfect hanging structure in the bathroom.

Perimeter frame

End profileAt this stage, the most important thing is to determine the height at which the installation will be carried out, and draw an ideal horizontal line. Rack ceilings are installed with a gap of 10-15 cm from the main plate.This distance is necessary for the placement of wiring and lighting fixtures. Here, of course, the question arises whether the new structure will not “put pressure” on you from above, but, as practice has shown, people quickly get used to the created conditions. Therefore, without hesitation, proceed to the implementation of the plan.

So, you have decided on the starting point from which the entire countdown will begin. The laser level will allow you to outline a flat line along which you will also mount the lath ceiling with your own hands.

U-shaped end profileAttach the U-shaped end profile along the line to the wall and drill a hole with a drill. We draw your attention to the fact that even though the profile is not plastic (since it accounts for the main load), it is easy to cut with scissors for metal. A screw with a dowel is inserted into the hole. In a similar way with a pitch of about 50-60 cm, the entire end profile (see photo).

We are confident that you have coped with this task with honor, and it is time to install the suspensions on which the supporting tires will be hung, and then the lath ceilings.

Suspension point

Mounting patternFor greater clarity, back to our example (see photo).

Denote the attachment points by 1, 2, 3, and 4.Then the distance of one meter is maintained between:

  • Point 1 and wall B.
  • Point 2 and wall B.
  • Point 2 and wall A.
  • Point 4 and wall A.
  • Dots 1 and 2, 1 and 3, 2 and 4, 3 and 4.
Having determined the exact place for each specific suspension (we remind that the installation is made through each meter), the part is fixed with a screw and dowel, in the hole drilled by the drill, as in the photo.

Car tires

Drilling holeYou have already made significant progress in repairing and have done a lot with your own hands. Still a little more and the lath ceiling (not plastic, but from modern aluminum alloy) will show off in your bathroom.

Carriers are attached to vertical hangers (along wall A). It is necessary to control the horizontal level of the rails. Keep in mind that they are quite flexible and easily deformed. Therefore, the installation must take into account this feature.

After you have completed all the preparatory stages, the most interesting thing remains - to assemble the slatted suspended ceiling, like Lego.

At the finish line

Panel mountInstallation of beauty in the bathroom enters its final stage. You can be proud of the result produced by yourself.
Before installing the decorative panels, carefully cut the desired length and do not forget to cut the holes for the lighting partitions in the canvas.All further actions are carried out simply elementary - the panel is inserted into the slots of the bearing tires and snaps into place, it can be seen in the photo. You do not even need to make much effort.

And between the decorative canvases insert an intermediate profile. That's all! Installation is complete. Just admire what you have created yourself! Now you can record a video course with you in the lead role and distribute it among friends and acquaintances.

Know how

Rack ceilings for the bathroom can be considered the best solution of modern design.
They provide a huge field of activity for the implementation of any innovative ideas. And extremely easy to install.

Unleash your imagination and show insignificant perseverance - your repair will be unique.
